rx II

With rx II, you have the power to create photorealistic, high quality real-time graphics, displayed directly on your screens and virtual sets.

rx II

Fastest graphics processing

Create photorealistic backgrounds and assets in real-time, and leave it to the rx II to deliver your graphics to the screen with minimal latency.

Order today

Rxii Productpage Thumbnail Getthefastestgraphicsprocessing
Rxii Productpage Thumbnail Createabetterstory

Create a better story

Engage your audience with content at the highest quality. Don't let your imagination be limited - get creative with generative content, augmented reality and pixel perfect graphics.

Reliable fast performance

The rx II is built to resist the toughest environments with a robust chassis and a powerful engine that reliably integrates with your ecosystem.

Rxii Productpage Thumbnail Reliableandfastperformance
Rxii Productpage Thumbnail Renderengineagnostic V2

Engine agnostic

The rx II seamlessly connects to Unreal Engine and other engines with RenderStream, allowing for a smooth, real-time workflow.

Powered by RenderStream

RenderStream allocates processing power across the rx range, enabling cluster rendering. This ensures that all render nodes are used to their maximum performance and leads to detailed content output at the highest quality.

Renderstream Main HW SW IS

Cluster rendering

Deliver high fidelity graphics safely by distributing rendering power across multiple render nodes.

Seamless synchronisation

Synchronise your physical stage with your virtual set via hardware, software, content engine and camera tracking

Unreal workflows

Immediately impact your productivity with dynamic control of the engine and automatic workflows on Unreal Engine, Notch and others.

Get in touch

Complete the form to learn more about the rx II and RenderStream. You will receive our latest software and hardware developments, insights and case studies on how our community are using this new technology to advance their production workflow.



Faster graphics processing

40% more graphics processing power than the rx, the rx II is powered by the latest Nvidia A6000 GPU.

Double RAM

Create larger and better quality environments with the powerful RAM.

Cluster Rendering

The rx range is a simple turnkey solution for cluster rendering, speeding up your workflow.

RenderStream

The purpose-built RenderStream protocol enables the rx render engine and vx1 and vx2 media servers to work in unison to create high-fidelity, low-latency xR workflows. The first year RenderStream license is included with your rx II.

Technical specifications

System Connectivity - I/O Video Output 1x DisplayPort 1.4 (GUI)
General Network 2x 1Gb/sec Ethernet
2x 10Gb/sec Ethernet
High Speed Network 2x 25Gb/sec Ethernet
Data/Peripherals 4x USB 3.0
Hardware Specifications Voltage 100-240VAC, 50-60Hz

For countries with variable power supply, we recommend a UPS to provide a consistent voltage
Power Consumption 539 W adjusted
Operating System Windows® 10 IoT Enterprise SAC
CPU Intel® Xeon® 3.2Ghz
Memory 96GB DDR4 RAM
GPU NVIDIA® RTX™ A6000
Environmental Tolerances Temperature: 5-30°C (40°-86°F)
Humidity: 20%-80% (non-condensing)
Altitude: 0-8850 ft (0-2700m)
Mounting System 2U 19” rack mount
Media Storage 1x 1.8TB NVMe SSD
Secondary Expandable Storage Up to 8x 2.5" SATA/SAS HDD
Physical Specifications Unit dimensions W: 438.5mm (17.26'')
H: 88.5mm (3.42')
D: 788.8mm (29.92'’)
Unit weight 32kg
Unit + Rack Handles 483.5mm (19.03'')
Rack depth with slides 914.6mm (36.01")
Bundled Accessories Bundled Accessories Slide Rail Kit
Rack Handles
Hardware Guide & IEC Power Cables:
- 2x USA
- 2x EU
- 2x UK
Support, Updates and Warranties License subscription package includes – Free software upgrades for the life of the machine
– 2 year return to base hardware warranty
– 12 month renderstream licence included
rx II specification sheet
rx II specification sheet Download – 253 KB
rx II architectural specification
rx II architectural specification Download – 53 KB
